Digital X-ray system for Casting Inspection

Configuration of Casting inspection system:

• X-ray source

• Flat panel detector

• Computer & software

• Mechanism device

• Lead protection cabinet

• Monitoring & warning system

Product Description of X-ray Pcb Inspection System:

Aolong's x-ray pcb inspection system is an advanced nondestructive testing (NDT) device that uses high-energy X-rays to penetrate metal castings and generate real-time images using a digital flat-panel detector. It is used to detect internal defects such as pores, cracks, inclusions, and shrinkage. Our x-ray pcb inspection system features data storage, image processing, and automatic defect detection, meeting stringent international testing standards.

Casting inspection system's primary inspection scope:

Our Casting inspection system is primarily used to inspect various metal castings, including parts made of steel, aluminum, magnesium, copper, and their alloys. It can detect internal defects such as pores, shrinkage cavities, slag inclusions, and cracks. Casting inspection system is particularly suitable for automotive engine blocks, cylinder heads, crankshafts, turbocharger housings, aerospace parts, pressure vessels, pipe joints, and precision machinery components.

x-ray pcb inspection system can inspect incoming materials:

Our x-ray pcb inspection system can perform nondestructive testing on purchased castings or semi-finished products, ensuring quality before they enter production. For example, in automotive parts factories, engine blocks or transmission cases are often scanned for internal structure before entering the machining shop. This allows defects such as shrinkage cavities and inclusions to be detected early, preventing substandard castings from entering production and minimizing subsequent processing losses. Aolong's x-ray inspection system is already in use on a customer's production line, ensuring continued production.

How does Digital detection of castings achieve real-time imaging?

In actual foundry production, Digital detection of castings' real-time imaging capability provides significant benefits to customers. Using a high-resolution digital detector, X-rays penetrate the casting and are quickly captured and converted into clear digital images, which are displayed directly on the user interface. Operators can instantly observe the internal structure of the casting on the x-ray inspection system screen and adjust process parameters directly, without waiting for film development or secondary processing, to prevent recurrence of similar problems.
